 CAN Bus Introduction to Diagnosis *Part II in 2018.1
History and principles of operation
Major components
Terminating Nodes
DLC pin layout mandatory & discretionary pins
How modules send and receive signals
Interpreting signals
CAN fault Diagnostics
 VVT Fault Diagnostics
System evolution and principle of operation
Oil control valve operation
Hydraulic Phaser types and operation
Failure scenarios and test procedures
Intro to Freevalve technology
 Suspension, Advanced Fault Diagnostics
Identifying and locating suspension noises
Jacking positions for Ball joint inspection
How to use Chassis Ears
 Evaporative Emission Systems
EURO Evaporative Emissions legislation
US Enhanced EVAP Systems
Vapour recovery systems and Capless fuel fillers
EVAP DTC’s and test procedures
 EGR Diagnosis
Petrol and Diesel EGR operation
Monitoring system sensors and logic
Checking EGR operation via Scantool
Diagnosing DTC’s showing failure example
 Advanced Safety Systems
Present Advanced Driver Aid systems
Advisory and Intervention systems
Related sensors Echolocation and Vision
Cameras and Infared sensors for vision
Feedback/warning systems
Intro to future systems V2V and V2I
