Modern Electrical Testing
Essential tests with Battery SoC chart
Voltage Drop testing and recommendation chart
Relays and different types
Duty Cycle vs Frequency
Switched Ground circuits showing NPN & PNP Transistors
Modern MOSFET Transistors
Electrostatic discharge precautions
 LED Lamp Testing
LED benefits
LED Headlight assembly/operation
LED Headlight Initialisation and generic manual procedure
Diagnosis and Replacement
LED lamp failure/testing/repair options
LED Lamp generic Diagnostic procedure
Examples of 2015MY Corolla LED systems/diagrams shown
 Park Assist Diagnosis
Circuit configuration showing Cruze example *Commodore example in ppt
Inspection flowchart procedure
2 pin vs 3 pin Sonar sensor differences & specs
 Aluminium Wiring Precautions
Why & benefits/precautions
Pure Aluminium and Aluminium Alloy cables
History and manufacturers using them
How to identify and repair/special terminals and tools required with Toyota part numbers
 Module Pairing
History
Explains Programming or Flashing/Calibration/Pairing/Configuration/Initialisation
Generic pairing procedure with Holden example
 J2534 Programming
Introduction/History
Holden Tis2Web access and step by step procedure
Pass through devices/options
