Introduction to 200 Series Landcruiser 2015

 Introduction to 200 Series Landcruiser

Engine options, specs, design features and updates – 1VD-FTV, 2UZ-FE & 1UR-FSE

1VD Diesel oil consumption issue and revised components

Key item service intervals/procedures and oil specs

Brake fluid Bleeding procedures *complete Brake Booster operation in 2015.1

Diesel Intercooler function and cautions with Spotlight fitment

Petrol engine Timing Belt procedures and changes from 100 Series Timing procedures

Cooling system refill/bleed points

Park Brake adjustment procedure

KDSS Kinetic Dynamic Suspension System overview/operation/Inspection

KDSS servicing/calibration/bleeding procedures with working pressure chart

Dual and Saddle Fuel Tanks Operation and Fault Diagnosis

Overview and benefits. Layout and designation

Jet pumps: overview and operation/ configurations

Fuel Sender Series configurations with Prado gauge chart

Fuel Sender Parallel configurations with BMW E60 – E62 in built diagnostic procedure

Fuel Sender Parallel to CAN configuration

Fuel Gauge fault Diagnostic Tips

Cam/Crank Correlation Oscilloscope Diagnostics

Intro to sensor types: Variable reluctance Transducers/Floating and Grounded VRT’s/Hall Effect

Identifying and translating waveforms with good and bad Scope examples

Running Compression waveforms using Scope and pressure Transducer to determine CKP and CMP relationship

AWD & 4×4 Systems Designs and Service Tips

Overview of different systems: Part-Time/Full-Time/On-Demand

Overview of Torque split configurations

Manual and Automatic Centre Locking Differential systems

Viscous couplings and Torque split control

AWD Service tips/intervals/procedures and recommended fluids for Honda Pump systems, Jeep Quadra Trac/Drive

AWD Service tips/intervals/procedures and recommended fluids for Haldex systems Gen 1-5 for VAG/Ford/Volvo/JLR

*also refer 2017.3 for switch control systems

No Start, No Code Diagnostics

Intro to process of elimination when Scantool presents no DTC’s for a no-crank no-start situation

Petrol Engine no start diagnostic flowchart

Diesel Engine no start diagnostic flowchart *also refer to Crank but No Start in 2020.1

Idle Stop/Start Systems – Why has it stopped working?

Intro to the implementation and benefits of ISS

Mazda i-stop Items to consider/monitor when ISS inoperative featuring system parameter specs and tests

Mazda i-stop system relearn procedure after repairs/Battery replacement

VW BlueMotion Items to consider/monitor when ISS inoperative featuring system parameter specs and tests
