 Understanding how Current makes it work
Benefits of monitoring current instead of Voltage/Resistance
Ohms law including Watts formula
Good and bad current draw scope samples – fuel pumps
*Fuse current loop connectors in ppt
 Pull up & Pull-down Resistors
Logic on how they work and aid ECU to display more accurate DTC’s
MAFM failure examples on Mits Triton
Difference between Live Data and Scan tool Data and using OBD side of Scantool
 Duty Cycle Control
Explanation of DC/frequency/PWM
Commodore 8 wire multi-function MAFM *same info also in 2018.1
Scope setup and how-to Math Channel
29 pages of good (1 bad) scope examples for lots of vehicles and systems
